3-1
3. ADJUSTMENT AND CHECK
3.1 Hull Unit Check
Note: Before conducting this check (at the dry dock) transmission must be stopped. Default
setting of TX power is OFF. Confirm that transmission is off as follows:
1. Turn on the power, and then press the [MENU] key to show the main menu.
MENU QUIT
H-SCAN SETTING...
V-SCAN SETTING...
OTHERS...
TX PULSE LENGTH-H : 9
TX POWER-H : 9
TVG-NEAR-H : 0
TVG-MEDIUM-H : 0
TVG-FAR-H : 0
AGC-H : 0
2ND AGC-H : 0
ECHO AVERAGE-H : 0
COLOR-H : COLOR 1
COLOR RESPONSE-H : COLOR CURVE 3
Main menu
2. Use the trackball to choose OTHERS and press the [MENU] key.
OTHERS
MENU QUIT
QUIT
ES1 SETTING...
ES2 SETTING...
ERASE MARKS...
DISPLAY SETTING...
ALARM & AUDIO...
PRESET, MEMORY CARD...
INITIAL SETTING...
OTHERS menu
