Customising the Control Unit
21
501 standard settings
The following table shows the options configured by the six standard Type settings on the 501 Control Unit:
Type
5 1 4 3 Source Label Input Gain Comms
● ● ● ● CD CD A2 0dB 1
● ● ● ● Radio RD A3 2dB 2
● ● ● ● LP LP A1 2dB –
● ● ● TV TV A5 8dB –
● ● ● ● Tape1 T1 A4 2dB –
● ● ● Tape2 T2 A6 2dB –
● CDR CR A2 0dB –
● Cable Cb A5 8dB –
● ● Text TX
=
n/a –
● ● VCR1 V1 A6 8dB –
● VCR2 V2 A4 8dB –
● LD LD A1 0dB –
=
Last valid input, displayed as LV.
Types 2 and 6 have the same source configuration as Type 1.
