Using the Video Features (501V only)
16
Selecting a video source
With the 501V Control Unit you select the video source you want
to watch in exactly the same way as selecting an audio source.
On the 501V Control Unit each source can be associated with
both audio input, and a video input.
For example, by default the TV source selects audio input A5 (for
TV sound), and video input V5 (for the TV picture).
Last valid option
The audio or video input for a source can be defined as LV (Last
Valid), in which case selecting the source will leave the audio or
video input unchanged.
For example, by default the CD source defines the video input
as LV. This allows you to select TV followed by CD to watch the
TV picture while listening to a compact disc, instead of the TV
sound.
To select a source
● Press Source (front panel) until the display shows the source
you require, or press the appropriate source key on the
remote control.
For example, if you select the
TV input the display will show:
TV65
By default, the following six video sources are available:
Source Label Video input Audio input
TV TV V5 A5
Cable Cb V4 A5
Teletext TX V5 LV
VCR1 V1 V1 A6
VCR2 V2 V2 A4
LD LD V3 A1
