Specifications
XENPAK MSA 10Gbps Transceiver XENPAK MSA 10Gbps Transceiver
Description
• XENPAK MSA compliant
• Data rate 10.313Gbps (10GbE rate)
• Size (121 x 36 x 17.4 mm)
• 70-pin compact connector
• XAUI INF( 3.125Gbps x 4 )
• MDIO
• APS power supply
• RoHS compliant
Part Number FIM82010Wxx FIM82020
Application 10GBASE-DWDM 10GBASE-ZR
Data Rate 10.313 Gbps
Wavelength
1528.77 to 1561.42 nm
(100GHz spacing)
1530 to 1565 nm
Distance 80 km
Optical Output Power -1 to 3 dBm 0 to 4 dBm
Extinction Ratio 9 dB
Receiver Sensitivity -24 to -7 dBm
Power Supply 3.3 V, APS (1.2 V)
Power Consumption 8.5 W (Max)
Dimensions (L x W x H) 121 x 36 x 17.4 mm / 4.76 x 1.42 x 0.69 inches
Operating Case Temperature 0 to 70 ºC
Specifications are subject to change without prior notice.
