WARNING: DO NOT remove inserts when heating or when the unit is
hot.
9.2.3
Stabilization and Accuracy
The stabilization time of the dry-well calibrator will depend on the conditions
and temperatures involved. Typically the test well will be stable to 0.1°C within
5 minutes of reaching the set-point temperature as indicated by the display. Ul-
41
9 Test Probe Calibration
Dry-well Characteristics
350
300
250
200
150
100
Bloc
k
T
emperature
°C
2
4
6
8
10
12
Ambient
Time in Minutes
Figure 7 Typical Heating Rate
350
300
250
200
150
100
Bloc
k
T
emperature
°C
2
4
6
8
10
12
Ambient
Time in Minutes
Figure 8 Typical Cooling Rate
