9140 Dry-well Calibrator
User’s Guide
36
Command Description
Command
Format
Command
Example
Returned
Returned
Example
Acceptable
Values
Display Temperature
Read current set-point
s[etpoint]
s
set: 9999.99 {C or F}
set: 150.00 C
Set current set-point to n
s[etpoint]=n
s=350
Instrument
Range
Read temperature
t[emperature]
t
t: 9999.9 {C or F}
t: 55.6 C
Read temperature units
u[nits]
u
u: x
u: C
Set temperature units:
u[nits]=c/f
C or F
Set temperature units to Celsius
u[nits]=c
u=c
Set temperature units to
Fahrenheit
u[nits]=f
u=f
Read scan mode
sc[an]
sc
sc: {ON or OFF}
sc: ON
Set scan mode
sc[an]=on/off
sc=on
ON or OFF
Read scan rate
sr[ate]
sr
srat: 99.9 C/min
srat:12.4 C/min
Set scan rate
sr[ate]=n
sr=1.1
.1 to 99.9
Read hold
ho[ld]
ho
ho: open/closed, 99.9 {C
or F}
ho: open,
30.5 C
Secondary Menu
Read proportional band setting
pr[op-band]
pr
pb: 999.9
pb: 15.9
Set proportional band to
n
pr[op-band]=n
pr=8.83
Depends on
Configuration
Read heater power
(duty cycle)
po[wer]
po
po: 999.9
po: 6.5
Configuration Menu
Calibration Menu
Read R0 calibration parameter
r[0]
r
r0: 999.999
r0: 100.7
Set R0 calibration parameter to
n r[0]=n
r=100.7
97.0 to 105
Read ALPHA calibration
parameter
a[lpha]
al
al: 9.999999
al: 0.003865
Set ALPHA calibration parameter
to
n
a[lpha]=n
al=0.003865
.002 to .006
Read DELTA calibration
parameter
d[elta]
de
de: 1.50
Read DELTA calibration
parameter
d[elta]=n
de=1.37
de: 9.9999
0–3.0000
Operating Parameters Menu
Serial Interface Menu
Read serial sample setting
sa[mple]
sa
sa: 9
sa: 1
Set serial sampling setting to
n
seconds
sa[mple]=n
sa=0
0 to 999
Set serial duplex mode:
du[plex]=f[ull]/h[alf]
FULL or HALF
Set serial duplex mode to full
du[plex]=f[ull]
du=f
Set serial duplex mode to half
du[plex]=h[alf]
du=h
Table 2 9140 controller communications commands
