System Controls
Xerox CopyCentre/WorkCentre 118 Quick Reference Guide 29
System Controls
Button/Indicator Function
1 Allows you to send and receive documents manually.
This button works only for faxing with the document
feeder; When the document is loaded into the feeder,
you can press the button only for sending. When the
document is not loaded into the feeder, you can press
the button only for receiving.
NOTE: Press the button before setting
the recipient or functions. Pressing the
button resets the specified recipient and set functions.
2 Allows you to use the direct send feature. Refer to
Direct Send in the Fax chapter on User Guide.
3 Indicates that data is being transmitted or received.
4 Indicates there is data stored in the machine.
5 Allows you to select options displayed on the screen.
Each press of the button moves you up one
option. Allows you to select options displayed on the screen.
Each press of the
6 Use these buttons to switch between screens. You can
also use them to move the cursor in the entry field.
7 Enters a pause in a telephone number when
transmitting a fax.
8 Allows you to specify the fax number or e-mail address
using Speed Dial codes.
9 Changes the language displayed on the screen.
10 Allows you to log in to the machine as the Key Operator,
and change the default settings. You can also register a
destination in the Address Book, a Fax Program, or a
bulletin board. Refer to Setups chapter on User Guide.
11 (Green light) Indicates whether the machine is in the power saver
mode. Also allows you to cancel this mode.
1 2 7 6
27
5 3 4 9 10 11 12
28 25 24 26 23 22 21 20 19 18 17 16 15 13
8
29 14
