VM-100YC - Technical Specifications

Technical Specifications

INPUT:

1 s-Video with loop,

1Vpp/75Ω (Y), 0.3Vpp/75Ω (C), on a

4-pin connector with a termination switch

OUTPUT:

10 s-Video,

1Vpp/75Ω (Y), 0.3Vpp/75Ω (C), on 4-pin

connectors

MAX. OUTPUT LEVEL:

1.9Vpp/75Ω (Y)

BANDWIDTH (-3dB):

275MHz

DIFF. GAIN:

0.03%

DIFF. PHASE:

0.03Deg

K-FACTOR:

< 0.05%

S/N RATIO:

81.4dB

CONTROLS:

Trimmers for "Y" level: -1.4 to +6dB; "C" level: -1 to +6.3dB

COUPLING:

POWER CONSUMPTION:

12V DC, 80mA

OPERATING TEMPERATURE:

0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE:

-40° to +70°C (-40° to 158°F)

HUMIDITY:

10% to 90%, RHL non-condensing

DIMENSIONS:

21.5cm x 16.2cm x 4.4cm (8.45" x 6.4" x 1.7") W, D, H

WEIGHT:

0.93kg (2lbs) approx.

ACCESSORIES:

Power supply

OPTIONS:

RK-1 19" rack adapter

Specifications are subject to change without notice at
