Page 118
Chapter 4 Specifications
4-53
4.4.4
Dimensions
The following dimensions apply to all GP-3500 Series units.
External Dimensions
AGP-35*0T
Unit: mm[in.]
AGP-3500L/AGP-3500S
Unit: mm[in.]
Top
Front
Right side
258.5[10.18]
270.5[10.65]
57[2.24]
5[0.20]
20
0.5[7.89]
2
12.5[8.37]
Top
Front
Right side
301[11.85]
313[12.32]
56[2.20]
5[0.20]
2
27[8.94]
239
[9
.41
]
