ST3000 Series Hardware Manual
3-28
3.3.2 Performance Specifications
„ Performance Specifications
Application
*1
*1. User active capacity.
FLASH EPROM 6MB
Data Backup
SRAM 320KB
Used lithium battery for backup memory
Int
e
rf
ac
e
Serial
Interface
COM1: RS-232C
Asynchronous Transmission:
Data Length: 7 bit/8 bit
Parity: none, Odd or Even
Stop Bit: 1bit/2bit
Data Transmission Speed: 2400bps to 115.2 kbps
Connector: D-Sub 9pin plug
COM2: RS-422/RS-485
*2
Asynchronous Transmission
Data Length: 7 bit/8 bit
Parity: none, Odd or Even
Stop Bit: 1bit/2bit
Data Transmission Speed: 2400bps to 115.2 kbps (RS-422/RS-485)
187.5 kbps (MPI)
Connector: D-Sub 9pin plug
*2. RS-485 is compliant with ST-3400 series units with revision code "A" or later.
About Revision (page 12)
USB Host
Interface
Conforms to USB1.1. (TYPE-A conn.) x 1
Power Supply Voltage: DC5V
±
5%
Output Current: 500mA (Max.)
Communication Distance: 5m (Max.)
CF Card
Interface
Compact Flash CF Card Slot (TYPE-II)
Clock
Accuracy
*3
*3. The ST’s internal clock has a slight error. At normal operating temperatures and conditions,
with the ST operating from its lithium battery, the degree of error is 65 seconds per month.
Variations in operating conditions and battery life can cause this error to vary from -380 to +90
seconds per month. For systems where this degree of error will be a problem, the user should
be sure to monitor this error and make adjustments when required.
±65 seconds/ month (at room temperature)
