Page 54
Chapter 3 Specifications
3-23
3.2.4
Dimensions
The following dimensions apply to all ST-3300 Series units.
Installation Fasteners Attached Dimensions
Unit: mm[in.]
155.5[6.12]
Top
167.5[6.59]
Front
59.5[2.34]
Right side
5[0.20]
1
23[4.84]
65[2.56]
Left side
Bottom
1
44.4[5.69]
135
[5
.31
]
134
.4
[5
.29
]
65[2.56]
50
[1.97]
50
[1.97]
