Chapter 1 Overview
1-9
„ Accessories for connecting GP2000H Series RS-232C or RS-422 Conver-
sion Adapter to GP3000H
*1 Be sure to read the restrictions to use the accessories.
1.2.2 USB Host Interface
Product Name Model No. Description
GP3000H Soft-type 3 m
Cable for GP2000H
Conversion Adapter
232C> (with connector) *1
GP3000H-CBLSD232-3M
The cable between the GP2000H Series
RS-232C Conversion Adapter and the
GP3000H, equipped with D-Sub
connector.
GP3000H Soft-type 10 m
Cable for GP2000H
Conversion Adapter
232C> (with connector)
*1
GP3000H-CBLSD232-10M
GP2000H Series RS-232C
Conversion Adapter *1
GP2000H-AP232
Conversion adapter to connect GP
operation data to RS-232C D-Sub and
power/DIO terminals.
GP3000H Soft-type 3 m
Cable for GP2000H
Conversion Adapter
422> (with connector) *1
GP3000H-CBLSD422-3M
The cable between the GP2000H Series
RS-422 Conversion Adapter and the
GP3000H, equipped with D-Sub
connector.
GP3000H Soft-type 10 m
Cable for GP2000H
Conversion Adapter
422> (with connector)
*1
GP3000H-CBLSD422-10M
GP2000H Series RS-422
Conversion Adapter *1
GP2000H-AP422
Conversion adapter to connect GP
operation data to RS-422 and power/DIO
terminals.
SEE 1.1.1 Restrictions (page1-7)
Product Name Model No. Description
USB Transfer Cable CA3-USBCB-01 (2m)
Downloads project data created with the
Screen Editor via the GP unit's USB I/F.
USB Cable FP-US00 (5m) Connects a USB printer. (TYPE-B)
USB-Serial (RS-232C)
Conversion Cable
CA6-USB232-01(0.5m)
Cable for converting a GP unit's USB
interface into a serial interface (RS-232C).
Allows connection to modems *1 or
barcode readers *1 that support RS-232C.
Can be used to transfer project data
created with the Screen Editor via a serial
interface. *2
*1 For supported models, refer to Pro-face’s support site “Otasuke Pro!”
(http://www.pro-face.com/otasuke/).
You can connect to this site by clicking the GP-Pro EX’s [Help (H)] menu-[Connect to Support
Site “Otasuke Pro!” (O)] command.
*2 Requires an RS-232C cable (prepared by user) for connection. For details regarding system de-
sign, refer to "
‹
Edit Mode Peripherals (page1-6)".
For instructions on how to connect between USB-Serial (RS-232C) Conversion Cable and your
PC, always refer to the "GP-Pro EX Reference Manual -> Transferring Projects and Data -> COM
Transfer Connections".
