SMART I/O User’s Manual
©1996 PEP Modular Computers GmbH March 12, 1996 Page 2 - 37
2
Chapter 2 SMART-BASE
2.8 Flash Utility
The flash utility allows ISaGRAF applications, a new ISaGRAF kernel or
other OS-9 modules to be loaded into FLASH memory. The SMART I/O
may be equipped with 1 MByte of memory depending on the version or-
dered. If an application is stored in FLASH then it will be loaded into the
system at start-up.
The main features of this utility are:
• Erase memory
• Fill memory
• Append memory
• Read memory
The following syntax should be observed:
flash -b[board]
Examples
To erase the FLASH:
Isa: flash -b=SMART -p=ff
To write a file to FLASH (base address is $D00000):
flash -b=SMART -d=d00000 -i=path/filename
To append a file to existing FLASH contents:
flash -b=SMART -d=d00000 -u -i=path/filename
